Features:
Applications:
Office machines
Automatic machines
Split air conditioners
- Resistance: 170 ohm
- Rated voltage: 12 Vdc
- Current: 60 mA
- Impedance: 200 ohm
- Phase: 4
- Step angle / step: 7.5° / 48
- Reduction ratio: 1/85
- Detent torque: 6.94 ozf.in
- Pull-in torque: 9.03 ozf.in
- Max. starting pulse rate: 350 pps
- Max. slewing pulse rate: 800 pps
- Temperature range: 113 °F
- Noise: 40 dB
- Cable: 450 mm AWG 1007#26
- Terminal: JST SXH-001T-P0.6
- Insulation strength: AC 600 V - 1 sec. cut-off current: 10 mA
- Colors:
- 1: B1: pink
- 2: A1: orange
- 3: A2: yellow
- 4: B2: blue
- 5: GND: red
- 6: GND2 (for MOTS2): brown
