Converts DC input current into a load independent output signal DC 4-20mA. Can be used for monitoring the current in solar cell installations, battery charging/discharging with the 4-20mA can be easily interfaced to a PLC or remote telemetry unit.
The current transducer features total galvanic isolation between input/output, high accuracy, low drifting by temperature, and wide temperature operational range.
Specifications:
- Power supply: 24 VDC
- Input: 0 to 100 A AC
- Output: 4 to 20 mA DC
- Accuracy: ≤1%
- Isolation(Input/output): ≥6000 VDC, 1 min
- Response time:
- Thermal drift: 600ppm
- Mounting: Screw
- Dimension: 73 x 25 x 74 mm
