Features:
- Operating speed (at no load): 0.14 sec/ 60° at 7.2 V
- Running current (at no load): 100 mA at 7.2 V
- Stall torque (at lock): 15 kg at 7.2 V
- Stall current (at lock): 1.5 A at 7.2 V
- Idle current (at stopped): 5 mA
- Operating frequency: 50 - 330 Hz
- Operating angle: 90°/135° (from 1000 to 2000 usec)
- Neutral position: 1500 usec
- Dead band width: 3 usec
- Rotating direction: Counter clockwise (from 1000 to 2000 usec)
- Pulse width range: From 500 to 2500 usec
- Overall dimension: 40 x 20 x 40.5 mm
- Weight: 64 g
- Connector wire gauge: #28 PVC
- Connector wire length: 320 ± 5 mm
- Horn gear spline: 25T/5.80
- Reduction ratio: 310:1
- Operating temperature range: -10°C - 50°C
- Operating voltage: 5 V - 7.2 V
- Connection: orange = PWM, red = VCC , brown = GND
