Features:
- for cables of 0.5 to 2.1 mm² / 14 to 20 AWG
- ratings: 50 V / 10 A
- can be crimped with: VTNCT
Specifications:
- number of contacts: 1 x 2 poles
- contact resistance: 10 mohm max.
- insulator resistance: 1000 Mohm min.
- dielectric strength: 1500 VAC for 1 minute
- current rating: 8-13 A
- voltage rating: 300 VAC
- pitch: 6.2 mm / 0.24"
- material:
- housing: Nylon UL 94V-0
- contact: phosphor bronze (tin-plated)
