Button or Sensor Triggered Audio Player with 25W*2 Stereo Amplifier

https://electronics123.odoo.com/web/image/product.template/12342/image_1920?unique=2a44ae9
(0 review)

SKU : FN-TG01S
Quantity on Hand : 2
Skill Level : Assembled and Tested

Buy 10, Get 5% Off!
Buy 100, Get 10% Off!

$ 46.95 46.95 USD $ 46.95

$ 46.95

Not Available For Sale

  • WeightMajor
  • WeightMinor

This combination does not exist.

Add to cart
Contact Us
Motion-Triggered Button-Triggered Sound File Upload Terminal Block Connection Built-in Amplifier Headphone Audio Output Additional Memory Capable Load / Busy Output In Enclosure Stereo Output Random Playback Feature

​FN-TG01S is a high quality button or sensor triggered audio player. It’s very flexible to use a

button/relay/PIR sensor/photoelectric sensor/proximity sensor(metal sensor), etc. to activate the sound. Also it provides many different

types of trigger modes (functions) to meet different requirements. With the distinctive features of flexible to work with a button or sensor, multiple trigger modes available (multifunctional), and simple wiring and easy to use, it’s possible to have it used in different kinds of

applications such as museums, stations, exhibition halls, animatronics, CCTV systems, industrial control systems, security equipment, smart workshops, etc.


Features:

  • Able to work with a button or normally open relay switch.
  • Able to work with a PIR sensor, photoelectric sensor, proximity sensor (metal sensor), etc.
  • Built-in high quality MP3 audio decoder.
  • Built-in 16MBytes flash memory and supports max. 32GB micro SD card.
  • Equipped with a type-C USB connector, and load audio files to the internal flash memory/micro SD card directly via USB connection to
  • computer. -The internal flash memory or micro SD card works as a USB flash drive on computer. No need any software/program.
  • Equipped with a class D 25watt x 2 stereo amplifier that can drive max. two 25watts (4-8 ohms) speakers directly for left and right channels.
  • 10 types of trigger modes available to choose according to actual needs.
  • Set a trigger mode easily in a config file (.txt file).
  • Adjustable sound volume through the volume knob for the speaker output.
  • Equipped with a 3.5mm audio jack for stereo output that can drive an earphone directly or connect to an external amplifier.
  • 1Able to drive an external equipment like a warning light simultaneously when it is playing a sound.
  • Uses a metal enclosure that is solid and durable.


Technical Parameters:

  • Working voltage: DC 12V-24V
  • Working current: ≥4500mA @12V (when it has two 25W speakers, and external load/warning light is not connected)
  • ≥2250mA @24V (when it has two 25W speakers, and external load/warning light is not connected)
  • Output current to an external load/warning light: ≤1000mA
  • Power consumption: ≤50W ( (external load/warning light not included))
  • Internal flash memory size: 16MB
  • Audio format: MP3
